Lincoln Electric 120/230V POWERMIG 211 Welder

The POWER MIG 211i MIG welder is a straightforward and dependable machine that’s ideal for MIG and flux-cored welding. This reliable diehard is your best friend on the farm, in the small shop, or for maintenance and repair work. The seven-segment display with basic knob controls and a simple three-step setup process gets you welding quickly – and when it’s time to move, the sleek case with multiple lift points make it extremely portable. If you’re looking for an incredibly simple, reliable MIG welder that won’t break the bank, the POWER MIG 211i MIG welder is ready to go to work for you.

KMS 5 Star Advantage Plan: We add one FREE extra year of warranty to every qualifying tool or machine purchased at KMS.

• Simple user interface - Seven segment display with basic knob controls.
• Process Capabilities - MIG, Flux-Cored and Spool Gun.
• Dual Input Voltage - 120V and 230V inputs so you can plug into any common power supply.
• Ergonomic Case - Sleek and robust case design with multiple lift points for ease of mobility around the shop.
• Robust and Reliable Wire Drive - Ensures proper and consistent feeding for optimal welding experience.
• Lightweight and Portable - Only 41 lbs

Specifications

• Product: MIG welder
• Manufacturer: Lincoln Electric
• Model: K6080-1
• Input Voltage: 120/230
• Input Current:
  • 120V: 15A
  • 230V: 15A
• Input Hertz: 60
• Input Power: 120/230/1/60
• Input Phase: 1
• Output Range:
  • 120V: 20-140A DC
  • 230V: 20-211A DC Max. OCV : 76V
• Polarity: DC
• Rated Output:
  • 120V: 95A/18.8/60%
  • 230V: 175A/22.8V/30%
• Input Voltage #1 (Voltage/Phase/Hertz): 120/1/60
• Rated Output #1A (Current/Voltage/Duty Cycle): MIG 95A/18.8/60% 75A/17.8V/100%
• Input Current at Max Rated Ouput #1 (Current): 20A
• Input Voltage #2 (Voltage/Phase/Hertz): 230/1/60
• Rated Output #2A (Current/Voltage/Duty Cycle): MIG 175A/22.8V/30% 90A/18.6V/100%
• Input Current at MAX Rated Output #2 (Current): 22.5A
• IEC Rating: IP21S
• Max Rating: 211A
• Output Range by Mode: MIG: 20-211A
• Number of Operators per Machine: 1
• Machines Communication Technology: Analog
• Work Lead Connector Type: Dinse
• Welding Gun Cable Assembly Length: Magnum PRO 100L
• Work Cable Length: 10’
• Spool Gun Compatible (Duty): Light
• Length: 22" (558mm)
• Width: 10.75" (273mm)
• Height: 15.5"(394mm)
• Weight: 41 lbs (18.6 kg)

Includes

• Magnum PRO 100L Gun 10 ft. (3.0 m) (K4528-1)
• 230V to 120V power cord adapter
• Work Cable and Clamp
• Adjustable Gas Regulator and Hose
• Gas Nozzle
• Gun Cable Liner (pre-installed in gun)
• Spindle Adapter
• Sample 2 lb (0.91 kg) Spool of SuperArc L-56 Mild Steel MIG Wire(EDO30631)
• 0.030" - 0.035" (0.8 - 0.9 mm) Drive Roll (Installed)
• 0.030" - 0.045" (0.8 - 1.1 mm) Knurled Drive Rolls
• and 0.025" - 0.035" (0.6 - 0.9 mm) Wire Guide (Installed)

Click PDF icon to download feature/ spec sheet
